offset printing machine

PZ Multi-color series sheet-fed offset printing machine---PZ41020 PERFORMANCE CHARACTERISTIC: Transfer cylinder is used to realize the high precision paper transferunder high speed running."Three-points" floating support of rubber cylinder keeps the pressure stable on and off.Double-inking structure ensures the stable thickness of ink for printing high quality pictures.Special touch method of impression makes little spread screen dot possible.High-positing gripper close enables smooth & stable paper transfer.WIDE RANGE OF APPLICABILITY: PZ Multi-color series sheet-fed offset press can be used to print top grade printing,including top grade pictures,advertisment samples,books and magazines color printing products and many kinds of packaging printing,etc.TECHNICAL SPECIFICATIONS: MODLEPZ41020Printing Speed p/h10000Max.Sheet Size mm720×1020Min.Sheet Siz mm360×520Max.Image Area mm700×1020Gripper Margin mm1012Weight of Paper g/m240-350Plate Size mm773×1030Blanket Size mm790×1052Thickness of Blanket mm1.9Max.Feeder Pile Height mm1090Max.Delivery Pile Height mm1110Machine Weight kg24460Overall Dimensions mm8240×3320×2060Power of Main motor kw22Power Requirements kw75Printing Uint4
